AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor

AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor
AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor

Large Image :  AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor

Product Details:
Certification: ISO, CCC, CE, RoHS, VDE
Contact Now

AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor

Description
Model NO.: AAAC 1120 Current: DC & AC
Sheath Material: Lsoh Material Shape: Round Wire
Wire Core Material: Red Copper Wire Model: Wdza-Yjy
Brand: Shanghai Shenghua Test Voltage: 3.5kv/5mins
Jacket Color: Orange Standard: As1531
Transport Package: Wooden Drum Specification: 4x25 Mm2
Trademark: SHAN CABLE Origin: Shanghai China
HS Code: 8544492100 Supply Ability: 6812km/Week

AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm HYDROGEN CG AS 1531 Overall Head Bare Conductor

TECHNICAL SPECIFICATION AND PACKING DETAIL
(HYDROGEN CG)
Description: Overhead AAAC conductor which is used for aerial power networks is suitable for aerial installation between poles.
Construction: The metallic conductor (AAAC) is consisted of aluminum alloy wires. The interstices of the inner layers are filled by grease compound which is suitable for the operating conditions of the conductor.
Standard:  AS1531
AAAC Cross section diagram

HYDROGEN CG

Properties of AAAC  7/4.5mm
ITEM DESCRIPTION UNIT TECHNICAL PARTICULARS
1 Code name   - HYDROGEN CG
2 Applicable Standards  - AS1531 ()
3 Type of conductor  - AAAC
4 Properties of Aluminum 1120 wires
  Nominal Diameter   mm 4.50
  Max. mm 4.545
  Min. mm 4.455
  Cross-sectional area  mm2 15.90
  Approx. Mass  Kg/km 42.9
  Min. breaking load  kN 3.66
  Minimum ultimate tensile stress  MPa 230
  Maximum DC resistance at 20ºC 20ºC Ω/km 1.84
5 Properties of Grease
  Type of grease    Anti-
Corrosion
  Color of grease    Offwhite
  Drop point of grease(min.)     ºC 120
  Approx. mass(NOMINAL)      Kg/km 3.04
6 Properties of Stranded conductor
  Stranding and wire diameter:
Aluminum wire /

7/4.50
  Lay length of outermost layer     times 168(-0,+7)
  Lay direction of outermost layer     Right hand
  Approx.Overall diameter  mm 13.5
  Cross-sectional area  mm2 111.3
  Approx. mass(without grease)  Kg/km 304
  Approx. mass(with grease)     Kg/km 307
  Minimum breaking load        kN 24.3
  Maximum DC resistance at 20ºC 20ºC Ω/km 0.266
Some not mentioned, please see AS1531.
PACKING DETAIL
Conductors shall be wound on a non-returnable fumigated drum or metal drum. The
required marking shall be printed with a weather-proof material on the outsides of drum
according to customer's requirement.


Cable Type Drum Length Drum Dimensions & Weights Material
D d B b A Net Weight
m mm mm mm mm mm kg
HYDROGEN CG   7/4.50 1500 1000 500 720 600 95 461 Fumigated wooden drum
Note:
1 The value"D" don't contain the dimension of seal.
2 The approximate weight of drum(Φ1000)  is 100 kilograms.
