2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV

2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV
2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV 2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV 2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV 2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV 2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV

Large Image :  2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV

Product Details:
Certification: CE, CCC, RoHS
Contact Now

2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV

Description
Model NO.: BV Application: House Wire
Conductor Material: Copper Sheath Material: PVC
Insulation Material: PVC Material Shape: Round Wire
Range Of Application: Fire Resistant Brand: Xinxin
Core: Single Core And Multiple Core Testing Voltage 5 Minute: 3.5kv
Rated Voltage: 0.6/1kv Working Temp. Of Conductor: 90ºC
Min.Installation Temp: >0ºC Transport Package: Roll
Specification: Copper/PVC Origin: China
HS Code: 85444921 Supply Ability: 10km/Day

Descriptions
Single-core non-sheathed cables with rigid conductor for general purposes
Code designation: 60227 IEC 05 (International), BV 300/500V(China)
H05VV-F/H05VV-R

Constructions
1.Conductor: Plain circular solid copper conductor, comform to IEC 60228 class 1
2.Insulation: PVC

Applications
Used as fixed wiring cable of rated voltage 300/500V.

Standards
International: IEC 60227
China: GB/T 5023-2008
Other standards such as BS, DIN and ICEA upon request

Technical data
Rated voltage:300/500 V
Max. Conductor Temp. in normal use: 70 ºC
Min. Bending Radius: 4 x cable O.D

Certificates
CE, RoHS, CCC, KEMA and more others at request

Specifications
2.5kv 450/750V Roll Copper/PVC China Electric Wire Electrical Cable BV 0
